Commercial Lighting | Wall Pack (High Output) - Wall Pack
Base Code: ES-WPS-B3-H1-BZ
Items marked FAST SHIP typically ship same day if order is placed before noon
$102.00
When the standard wall pack isn't enough wall pack.
The high-output version of the Wall Pack for perimeter applications that need real throw — parking lot edges, large loading docks, and building faces where the standard output falls short.
Selectable 60/100/120W covers a wide range of mounting heights and fixture spacing from one part number, at up to 150 lm/W.
UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).
LED Lighting
This product uses energy efficient and long lasting LED's.
Features
- Field-selectable wattage (60/100/120W)
- Selectable CCT
- IP65 waterproof
- High efficacy (up to 150 lm/W)
- Sensor ready
- 5-year warranty
Ideal Applications
- Parking lot perimeters
- Large loading docks
- Building exteriors
- Security lighting
Mounting Options
- Surface Mount
Features
- Field-selectable wattage (60/100/120W)
- Selectable CCT
- IP65 waterproof
- High efficacy (up to 150 lm/W)
- Sensor ready
- 5-year warranty
- Parking lot perimeters
- Large loading docks
- Building exteriors
- Security lighting
Product Description
The high-output version of the Wall Pack for perimeter applications that need real throw — parking lot edges, large loading docks, and building faces where the standard output falls short.
Selectable 60/100/120W covers a wide range of mounting heights and fixture spacing from one part number, at up to 150 lm/W.
Key Features
Ideal Applications
Mounting Options
<li>Surface Mount</li>
Specifications
| Dimensions (May Vary by Model) | |
| Weight | 1.00 lb |
Construction
Durable die-cast aluminum housing with a bronze finish and striped glass lens. The fixture is IP65 rated for wet locations and includes an integrated photocell with bypass capability. Designed for demanding outdoor applications with 6kV surge protection.Illumination
The High Output Essential Series Wall Pack features selectable 60W, 100W, and 120W settings with selectable color temperatures of 3000K, 4000K, or 5000K. Its high-efficiency LED system provides powerful, uniform outdoor illumination with a CRI greater than 80.
Emergency Operation
An optional emergency driver is available to provide backup illumination during a power failure. The emergency driver must be ordered separately and installed in the field.Battery - Battery Backup
The High Output Wall Pack is compatible with the EB-8W-08300DO Emergency Driver. Emergency driver unit only; field installation is required.
Operational Temperature
Temperature Rating: -40°F to 122°FPhotometrics
Total Luminaire Lumens : 9,080 / 15,140 / 18,170 lm
Electrical Components
Designed for 120-277V, 50/60Hz electrical systems. The fixture supports smooth 0-10V dimming and features a power factor of at least 0.9, maximum THD of 20%, driver efficiency of at least 90%, and 6kV surge protection.Electrical Specifications
Installation
Designed for direct surface mounting on exterior walls. The integrated photocell can be activated or bypassed according to the application. Ideal for building perimeters, entrances, walkways, loading areas, parking facilities, and other commercial outdoor locations.
