Exit Sign Mounting Configurations Explained

When deciding what type of exit signs or emergency lights to purchase, mounting configuration can play a very important role. To those not familiar with mounting configurations, the terminology can be very confusing. The following photos will help you not only to understand what each term means, but will clarify which mounting configuration is best for your installation.

Flush Mount / Wall Mount:

Does not involve the use of mounting canopy.  Units typically have knock-out pattern on back plate to mount directly to junction box. (May also allow for “Ceiling Mount” in emergency light fixtures only.)

Wall Mount Exit Sign

Ceiling Mount:

Typically requires use of mounting canopy from top of fixture. Some units may further specify Drop Ceiling/New Construction or Sheet Rock/Remodel applications. Use of ceiling mount for exit signage may require double face. (May also allow for “Wall Mount” in emergency light fixtures only.)

Ceiling Mount Exit Sign

Side Mount:

Sometimes confused with “Wall Mount”, side mounting typically requires use of a mounting canopy. Canopy is affixed to the side of the unit and then attached to wall. Use of side mount for exit signage may require double face.

Side Mount Exit Sign

Wall Mount Angle Down:

Special mounting configuration mostly limited to edge lit exit signage. May require mounting canopy affixed to the top of the unit and then attached to wall. Edge lit face then rotates down. In recessed applications, the face itself may be curved down.

Edge Lit Exit Sign Mount

Recessed Mount:

Commonly used for ceiling mount units in which housing is actually located above the ceiling. Some units may further specify Drop Ceiling/New Construction or Sheet Rock/Remodel applications.

Recessed Mount Exit Sign

Pendant Mount:

This configuration requires the use of a pendant kit (which may be an optional add-on). Allows ceiling mountable units to be suspended from a high or sloped ceiling to be more visible.

Pendant Mount Exit Sign

Note that not all installation configurations may be available for every sign, help is available via on-line chat, phone (877-352-3948) or email (orders@exitlightco.com) from 5am-5pm PST if you have additional questions or require assistance.
