Essential Series Architectural Linear 8 ft - Architectural Linear
Base Code: ES-AL-L8-S1-WH
Items marked FAST SHIP typically ship same day if order is placed before noon.
$0.00
Product Description
The Essential Series Architectural Linear 8 ft fixture combines up and down LED illumination with a linkable design for commercial spaces. Its 8 ft format supports continuous runs and custom configurations while providing visual comfort and balanced, flicker-free performance.
Overview
The Essential Series Architectural Linear 8 ft fixture combines up/down LED illumination, a linkable design, and modular flexibility for commercial spaces. Field-selectable wattage and five CCT options support custom layouts with efficient, flicker-free performance.Installation
Pendant or ceiling mounting. The linkable modular system supports continuous runs and custom layouts.Dimensions
| Weight | 0.00 lb |
Warranty
Backed by a 5-year limited warranty.
Order Information
| Catalog Number | Size | Wattage Selectable | Down Lumens Selectable | Up Lumens Selectable | Total Lumens Selectable | CCT Selectable | Voltage | Finish |
|---|---|---|---|---|---|---|---|---|
| ES-AL-L8-S1-WH | 8 ft | 60/70/80W | 6230/7260/8300 lm | 2270/2650/3030 lm | 8500/9910/11330 lm | 30/35/40/45/50K | 120-277V | White |
Construction
Aluminum housing with a frosted lens and white finish. The modular architectural linear system is designed for linkable continuous runs and balanced up/down illumination.Illumination
The 8 ft model provides field-selectable 60/70/80W output with selectable 3000K/3500K/4000K/4500K/5000K CCT. Down-light output is 6,230/7,260/8,300 lm; up-light output is 2,270/2,650/3,030 lm; total output is 8,500/9,910/11,330 lm.Emergency Operation
Optional emergency operation is available with a separately ordered emergency driver; field installation is required. Compatible with EB-15-KM15S Emergency Driver; field installation required.Operational Temperature
-40°C to 50°C without emergency; 0°C to 40°C with emergency.Safety Codes and Compliance
DLC Premium listed; UL/cUL listed; IP40 rated; 5-year warranty.Electrical
120-277V, 50/60 Hz operation with smooth 0-10V dimming, power factor >=0.9, maximum THD <=20%, and flicker-free driver performance.Electrical Specifications
- Input voltage: 120-277V
- Dimming: 0-10V
- Power factor: >=0.9
- Maximum THD: <=20%
Lighting Diagram
Total Luminaire Lumens: Down: 6,230 / 7,260 / 8,300 lm; Up: 2,270 / 2,650 / 3,030 lm; Total: 8,500 / 9,910 / 11,330 lm
- CCT: 3000K/3500K/4000K/4500K/5000K
- Efficacy: Up to 135 lm/W at 4000K
- CRI: Greater than 80
- Beam angle: 100°
Compatible Accessory
| Accessory | Compatible Product |
|---|---|
| Suspension Mount Kit | ACC-AL-SUS |
| Ceiling Mount Kit | ACC-AL-SMB-CEIL |
| L Connector | ACC-AL-CONN-L |
| T Connector | ACC-AL-CONN-T |
| X Connector | ACC-AL-CONN-X |
| Y Connector | ACC-AL-CONN-Y |
| Power Cord (Dimming) | ACC-AL-CORD-1P8M-DIM |
| Emergency Driver | EB-15-KM15S |
