Thin Red LED Exit Sign - White Housing

Base Code: LEDT-R-W-BB

Items marked FAST SHIP typically ship same day if order is placed before noon

Thin Red LED Exit Sign - White Housing
Processing...

Qty
A thin, low profile Exit Sign with standard Red LED letters.  If you're looking for an exit lighting solution that doesn't take over your decor, this is the sign for you. This sign still meets all the same requirements and listings as a standard unit and can be used almost anywhere!  This exit sign operates on either  120 or 277 VAC.

Compatible Battery:  BAA-12

This product has been tested to meet all required U.S. standards by Underwriters Laboratories, Inc. (UL), the most widely recognized U.S. nationally recognized testing laboratory (NRTL).

UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).

LED Lighting

LED Lighting
This product uses energy efficient and long lasting LED's.

Battery Included

Battery Included
This product contains a battery for backup power. The battery must be connected during installation.

Features

  • UL 924, NEC, OSHA and NFPA 101 Life Safety Code compliant
  • Injection-molded, high-impact, UL94 V-0 thermoplastic construction
  • 120-277 VAC operation
  • Universal mounting pattern knock-out in back plate for J-box mounting
  • Knock-out left/right arrows
  • Test switch and charge indicator
  • Innovative and easy installation in minutes

Specifications

Dimensions (May Vary by Model)
Width11.96"
Height7.59"
Depth1.02"
Weight5.00 lb

What's included?

  • Thin Red LED Exit Sign
  • Two "EXIT" Faceplates (with optional knockout arrows)
  • One Blank Faceplate
  • Mounting Canopy, Installation Instructions & Hardware (Inside Unit)
  • Battery (Inside Unit) - Must connect the battery after installation

Construction

The LEDT series is constructed from injection-molded, high-impact, engineering-grade, UV-stabilized, UL 94 V-0 thermoplastic. White housing is standard.

Illumination

Long-Lasting, efficient Red LEDs.

Emergency Operation

Upon failure of the normal utility power, an internal solid-state transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates recharging a discharged battery within 24 hours.

Battery - Battery Backup

The LEDT Thin Exit Sign series is designed with a maintenance-free 1.2V 1000mAh NiMH battery that provides an emergency duration of 90 minutes. Recharge time of the battery is 24 hours.

Operational Temperature

Temperature Ratings
Standard Option 0°C to 40°C / 32°F to 104°F

Electrical Components

Dual voltage input 120/277 VAC operation. LED display indicates AC/ON. An external push button test switch allows maintenance personnel to quickly determine the operational status of the unit.

Installation

The LEDT is suitable for surface wall, side, and top mounting via included canopy. Snap together design allows for quick and easy installation. Knock-out chevrons for customized egress signage. The LEDT exit sign can be installed in damp location areas.

Mounting Configurations   Mounting Configurations Explained

PDF Download   View Installation Instructions

Dimensions

Thin Red LED Exit Sign - White Housing Dimensions

Customer Questions & Answers
Post a question and have an expert answer



Q Jim Jackson • 07/16/2020, 2:28:49 PM Can you get replacement LEDs for the e it sign
A Exit Light Co. Replacement parts are not available.
Q Kiran • 07/18/2020, 6:49:25 AM hello! this is probably a really dumb question, but is there an option to turn the sign on/off with a button on the side or something? thank you.
A Exit Light Co. These units do not have an on/off button or switch.
Q Ronald E Merkt • 08/10/2020, 10:42:36 AM Am I understanding this right? This is the complete EXIT sign set up with battery back up. If I have signs to replace this is all that I will need. The reason for this question is the price sounds to low. Just making sure that I am going to get everything that I need for my job.
A Exit Light Co. Yes, this unit comes with the mounting canopy, extra faceplate and battery. We manufacture and ship direct.
Q Laticia bennett • 08/19/2020, 1:11:13 PM I need to know the country or origin for the Thin Red LED Exit Sign - White Housing Base Code: LEDT-R-W-BB
A Exit Light Co. This unit is manufactured in China.
Q Lawrence O Ross • 07/01/2021, 1:54:01 PM does this sign have a double face with exit showing on both sides if not do you have one?
A Exit Light Co. Hello This signs comes with an option for either single sided EXIT or double sided exit with an included faceplate.
Q Reco Morrow • 07/08/2021, 8:56:24 PM So are the exit signs hard wired in and once power goes out the back up battery kicks in
A Exit Light Co. Hello Reco, That is correct. Upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
Q Michel Larcheveque • 10/06/2021, 3:02:50 PM What is the Amperage at 120V, and 277V?
A Exit Light Co. The amperage is 0.02 and 1.6W.
Q Mark W Schmucker • 02/27/2024, 2:50:02 PM Is this unit Battery only or is it hardwired?
A Exit Light Co. The LEDT-R needs to be hardwired to the building's electrical system. The unit will switch to using the included battery when power loss is detected and will stay illuminated for for a minimum of 90 minutes.
